Well... I'm semi skint at the mo but slowly tidying up a few loose ends on the silvia. I've got it to a good state now and replaced a couple of old/worn parts here and there and now I just need to aesthetically tidy things up (well.... actually I would like to recirc my SSQV so if I have to buy hosing for that I thought I may aswell do the rest to match in new fresh samco kit)
Anyway... Essentially, just wondering if anyone can let me know what diameters I need for the different hoses pictured below. Sorry about the quality of the pics they were taken on an old school camera phone but here goes:
Yellow - Hardpipe to throttle body
Pink - Hardpipe to intercooler piping (turbo side)
Green - Runs over fan shroud
Dark Blue
Light Blue - Hardpipe to turbo
Purple - Hardpipe to SSQV
Red - Overflow pipework?
Anyone any idea on the diameter of the cusco piping for the catch tank? Or for those who dont run a cusco catch tank.... essentially the diameter of the rocker cover breather pipe?
Actuator vac pipe?
Defi boost gauge vac pipe?
SSQV vac pipe?
Anything else I've missed? Cheers guys!!!
Anyway... Essentially, just wondering if anyone can let me know what diameters I need for the different hoses pictured below. Sorry about the quality of the pics they were taken on an old school camera phone but here goes:
![](/discuss/proxy.php?image=http%3A%2F%2Fimg.photobucket.com%2Falbums%2Fv465%2FSiScort%2FHoses%2Fhose1.jpg&hash=377188db65430776e247f5cac841c43f)
![](/discuss/proxy.php?image=http%3A%2F%2Fimg.photobucket.com%2Falbums%2Fv465%2FSiScort%2FHoses%2Fhose2.jpg&hash=d36fe0237464c8ea8812ef92b7593801)
![](/discuss/proxy.php?image=http%3A%2F%2Fimg.photobucket.com%2Falbums%2Fv465%2FSiScort%2FHoses%2Fhose3.jpg&hash=46a0f1b50d5f6200c2a2914efa14af91)
![](/discuss/proxy.php?image=http%3A%2F%2Fimg.photobucket.com%2Falbums%2Fv465%2FSiScort%2FHoses%2Fhose4.jpg&hash=c13391a003801eb5e1f46c132955b48e)
![](/discuss/proxy.php?image=http%3A%2F%2Fimg.photobucket.com%2Falbums%2Fv465%2FSiScort%2FHoses%2Fhose5.jpg&hash=868a3cb5d4487e9cec43dd3568619c20)
So, if anyone in the know could complete this list or any within the list it'd help. I've coloured them for ease in good old paint
Yellow - Hardpipe to throttle body
Pink - Hardpipe to intercooler piping (turbo side)
Green - Runs over fan shroud
Dark Blue
Light Blue - Hardpipe to turbo
Purple - Hardpipe to SSQV
Red - Overflow pipework?
Anyone any idea on the diameter of the cusco piping for the catch tank? Or for those who dont run a cusco catch tank.... essentially the diameter of the rocker cover breather pipe?
Actuator vac pipe?
Defi boost gauge vac pipe?
SSQV vac pipe?
I know I need 30mm diameter already for my recirc hosing
Anything else I've missed? Cheers guys!!!
